Specifications |
| Dimensions | With standard battery: 158mm(L) x 79mm(W) x 13.7mm(D), With extended battery: 158mm(L) x 79mm(W) x 17.3mm(D) |
| Weight | 8.32 oz./236 g with standard battery; 269 g with extended battery |
| Display | 5.0 in. color HD (1280 x 720); LED backlight; Corning® Gorilla® Glass |
| Imager Window | Corning® Gorilla® Glass |
| Touch Panel | Capacitive Touch Panel; multi-touch |
| Power | Removable/serviceable rechargeable Li-Ion Standard battery: 3300 mAh/12.54 Wh, Extended battery: 5260 mAh/20.25 Wh |
| Expansion Slot | One 128 GB micro SD slot |
| SIM | 1 Nano SIM slot; optional eSIM (TC26 only) |
| Network Connections | TC21: WLAN, WPAN, USB 2.0 hi-speed (host and client), TC26: WWAN, WLAN, WPAN, USB 2.0 hi-speed (host and client) |
| Notifications | Audible tone; multi-color LEDs; vibration |
| Keypad | On-screen keypad |
| Audio | Speaker - 1 Watt Voice support (Internal speaker/receiver and microphones) |
| Buttons | Scan on each side; volume up/down; power; push-to-talk (PTT) keys |
| Scanning | SE4100 1D/2D imager, SE4710 1D/2D imager, Camera scanning (SKU dependent) |
| Camera | Rear camera 13 MP; optional front camera 5 MP |
| NFC | Integrated; MIFARE, ISO 14443 A&B , FeliCa , ISO 15693 and NFC Forum supported cards; read range up to 50 mm; support for Apple VAS1 / Google Smart Tap1 |
| CPU | Qualcomm Snapdragon?? 660 octa-core, 1.8 GHz or 2.2 GHz (select configurations) |
| Operating System | TC21: Upgradeable to Android 14, TC26: Upgradeable to Android 14 |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -30°C to 70°C |
| Drop Specification | 5 ft./1.5 m drop to concrete per MIL-STD-810G with optional protective boot 4 ft./1.2 m drop to concrete per MIL-STD-810G across operating temperature |
| Tumble Specification | 550 tumbles, 1.6 ft./0.5 m with boot |
| IP Rating | IP67 |
