Get the R5 UHF Wearable Bluetooth RFID Reader, a wearable, lightweight RFID reader offering a 2000 mAh removable battery, 900+ tags/sec read rate, Up to 14m read range, IP Rating 65, etc.

Write a review
Features
Operating Frequency: 865–867 MHz Ultra High Frequency(UHF)
Air Interface Protocol: ISO 18000-6C EPC Clas 1 Gen 2
Bluetooth: Bluetooth 4.0
Battery: 2000 mAh (removable)
Max Read Range: Up to 14m
Enquire Now
Be the first to review this item
 Write a review

The latest R5 UHF Wearable Bluetooth RFID Reader by Chainway is an innovative solution among UHF RFID readers, offering a lightweight, small, wearable design, ideal for long-hour operations in retail and supply chains. The R5 wearable RFID reader comes equipped with Impinj’s E710/R2000 ICs, which ensure greater efficiency in tag-intensive environments.

Chainway’s R5 smart RFID scanner with its high-performing microchip ensures a max read range of 14m in indoor and outdoor conditions and the high RF sensitivity of E710 ensures optimum performance overcoming interference.  The R5 UHF RFID Reader supports EPC C1 gen2 and ISO 18000-63 communication standards and offers a read rate of 900+ tags/sec, apt for most retail and inventory management operations.

This wearable RFID reader also comes with 2000 mAh and supports Android/ iOS devices for enhanced RFID capabilities. The R5 Wearable Bluetooth RFID Reader is suitable for warehouse, retail, and other applications, which provides users with more flexibility, improving overall productivity.

Applications of R5 UHF Wearable Bluetooth RFID Reader

• Retail operations,

• Inventory management,

• Asset tracking,

• Warehouse management, etc.

Specifications
Operating Frequency 865–867 MHz Ultra High Frequency(UHF)
Air Interface Protocol ISO 18000-6C EPC Clas 1 Gen 2
Bluetooth Bluetooth 4.0
Battery 2000 mAh (removable)
Max Read Range Up to 14m
Operating Temperature -20 °C to +50 °C
Dimensions 108 mm × 78 mm × 18 mm
Keypad ON/OFF, Scan
Port USB Type C
Charging Current 5 V / 1.5 A
Charging Duration 2 hours
SDK Android / iOS SDK Supported
Antenna Circular Polarized Antenna (3dBic)
Power 1W (30dBm, support +5~+30dBm adjustable)
Fastest Read Rate 900+ tags/sec
IP Rating IP65
Bluetooth Bluetooth Low Energy (BLE)
USB Type C USB connection to realize data transfer
